EE 2115-01 - Lec 20 - 2026_10_12

Overview

Hiren Trada introduces capacitor transient behavior through an RC circuit, explaining how a capacitor charges and discharges over finite time and why its voltage cannot change instantaneously. He derives the time constant τ = RC and the general first-order response vC(t) = Vf + (Vi − Vf)e^(−t/τ), then relates the exponential curve to practical thresholds and capacitor sizing.

Key takeaways

For a series RC circuit, the time constant τ = RC controls how quickly capacitor voltage changes; increasing either R or C slows the transient.
A capacitor’s voltage cannot jump instantaneously because iC = C·dVC/dt would require infinite current for an instantaneous voltage change.
The general step response vC(t) = Vf + (Vi − Vf)e^(−t/τ) accounts for both the starting voltage and the final voltage, making it useful for charging and discharging cases.
After one RC time constant, the capacitor has completed about 63.2% of the voltage change; after five, it is about 99.3% settled.
An unknown capacitance can be found experimentally by measuring an RC transient: determine τ from the response and compute C = τ/R using a known resistor.
In a physical capacitor, electrons move through the external circuit and build opposite charges on the plates; the insulating dielectric prevents ordinary conduction between them.

Chapters

0:00 Capacitors, Inductors, and Everyday Energy Storage

Capacitors and inductors store energy, unlike resistors, which dissipate energy as heat.
Hiren Trada describes capacitors and inductors as duals whose equations share a structure with voltage and current interchanged.
Capacitive touchscreens detect changes in capacitance, while camera flashes release energy stored from batteries.

6:00 Why Capacitor Charging Is a Transient Process

Energy entering or leaving a capacitor takes finite time; charging and discharging are not instantaneous.
The changing voltage or current during energy transfer is called transient response; a settled, constant value is steady state.
Circuit responses can occur over milliseconds, microseconds, or nanoseconds, even when a camera flash stores energy for a more noticeable interval.

10:00 RC Circuits, Step Inputs, and Frequency Filters

A resistor-capacitor circuit can take its output across either component, producing different circuit behavior.
RC networks can act as filters: their response depends on signal frequency, allowing some frequencies through while attenuating others.
For a DC step input, capacitor voltage rises from its initial value toward the input voltage as current flows through the series resistor.

15:00 Voltage Equalization and the RC Time Constant

In the series RC example, charging current decreases as the capacitor voltage approaches the input voltage; at equal voltage, the ideal circuit current becomes zero.
A capacitor obeys iC = C·dVC/dt, or vC = (1/C)∫iC dt, linking current to the rate of voltage change.
The time constant τ = RC characterizes the response speed for both charging and discharging; larger resistance or capacitance increases τ.

20:00 What Happens Across a Capacitor’s Insulating Dielectric

A capacitor consists of two conducting plates separated by an insulator, such as air.
Electrons move in the external circuit and accumulate on one plate while being removed from the other, creating the charge imbalance measured as capacitor voltage.
In the circuit model, capacitor current does not represent electrons conducting through the insulating dielectric.

23:00 Step Response and Capacitor Voltage Continuity

A capacitor’s step response approaches its target voltage exponentially, rather than reaching it in an instantaneous jump.
Because iC = C·dVC/dt, an instantaneous voltage change would require infinite current, which is physically impossible.
The notation t = 0− means just before an input is applied and t = 0+ means just after; capacitor voltage is continuous, so VC(0−) = VC(0+).

28:00 Deriving the First-Order RC Differential Equation

In a series RC circuit, the source, resistor, and capacitor carry the same current.
Substituting iC = C·dVC/dt and Ohm’s law into the loop equation yields a first-order differential equation for capacitor voltage.
The resulting equation contains 1/RC = 1/τ, showing how the circuit’s resistance and capacitance determine response speed.

33:00 The General Exponential Formula for Capacitor Voltage

For a step toward final voltage Vf from initial voltage Vi, the response is vC(t) = Vf + (Vi − Vf)e^(−t/τ).
For an initially discharged capacitor charged toward V0, this becomes vC(t) = V0(1 − e^(−t/τ)).
The initial-value term matters because a capacitor may already hold voltage when a new input is applied; the same form also describes discharge.

41:20 Interpreting Initial, Final, and Time-Constant Values

Vf is the eventual capacitor voltage, while Vi is the voltage stored at the start of the transient.
For a discharge to zero, the final value is zero and the stored initial voltage decays exponentially.
The general equation applies to different initial conditions and, as a first-order response form, has a corresponding application to inductor transients.

46:00 RC Charging Benchmarks and Estimating Capacitance

After one time constant, a capacitor reaches about 63.2% of the way from its initial voltage to its final value; after two, about 86.5%.
Five time constants is the conventional practical point for treating charging or discharging as complete: the response is about 99.3% settled.
To estimate an unknown capacitor, apply a known step with a known resistor, measure the transient to determine τ, then calculate C = τ/R.
A square-wave input and oscilloscope can display repeated capacitor charging and discharging waveforms.
