CSCE 611 Fall 2026 Lecture 6: Even more SystemVerilog

Overview

Jason D. Bakos reviews RISC-V and SystemVerilog quiz concepts, then connects structural HDL, signal driving, and FPGA lab setup to simulation and behavioral coding. The lecture develops SystemVerilog test benches and explains `initial`, `always_comb`, `always_ff`, sensitivity lists, latch inference, flip-flops, and self-checking tests for the seven-segment-decoder labs.

Key takeaways

For a RISC-V loop over four-byte integers, an element bound of 10 corresponds to a 40-byte offset when the loop counter is also used for address calculation.
SystemVerilog's four-state `logic` values distinguish known `0` and `1` from unknown or conflicting `X` and high-impedance `Z`; conflicting active drivers can produce `X` in simulation.
`always_comb` blocks must assign every output on every possible control path; a missing assignment makes synthesis infer storage such as a latch.
Use `always_ff` with a clock edge for flip-flop-based sequential logic, and prefer edge-triggered registers over latches because they are easier to analyze for timing.
A self-checking test bench combines input stimulus, a short settling delay or clock phase, and output comparisons so repeated simulation runs can detect failures automatically.
The Lab 2 seven-segment decoder work is reused in Lab 3, where a CPU replaces the direct switch-to-decoder connection and processes the same FPGA inputs and displays.

Chapters

0:00 RISC-V Loop Translation and the Missing Branch Condition

The C loop uses an array of four-byte integers, so its assembly loop limit is 40 bytes rather than 10 elements.
Registers hold the array base, loop index, temporary addresses, and loaded values; the missing instruction checks whether the index has reached the loop bound and branches to exit.
The loop loads and adds `a[i-1]` and `a[i-2]`; the lecture notes a quiz-code typo and a possible missing store separately from the intended branch answer.

6:53 Bit Shifts, Simulation, Synthesis, and Multiple Drivers

Left-shifting one 16-bit half and right-shifting the other, then OR-ing them, swaps the upper and lower halves of a register and destroys the original value.
SystemVerilog supports both simulation and synthesis, and can describe structural as well as behavioral hardware.
Two continuous assignments that drive one signal can conflict; simulation represents the conflict as `X`, while a tri-state `Z` driver represents a disconnected output.

11:36 Four-State Logic and Signal Values Across Module Hierarchy

A SystemVerilog `logic` value can be `0`, `1`, `X`, or `Z`; `X` flags unknown or conflicting values, while `Z` represents high impedance.
Named port connections can rename signals across module boundaries: the `bottom` module instance receives `a=1` and produces `y=0` when its logic inverts the input.
A signal can be driven indirectly through a module output, so checking only the top-level assignments may miss a multiple-driver conflict.

19:34 Structural HDL, Bit Manipulation, and the Lab 2-to-Lab 3 Path

Structural HDL connects module instances through signals; behavioral HDL in the earlier material used `assign` statements and the ternary operator.
Bit slicing selects ranges such as `a[2:0]`, concatenation orders the most-significant bits on the left, and replication can duplicate a bit into a wider signal.
Lab 2 connects groups of four FPGA switches to seven-segment decoders; Lab 3 reuses the switches, displays, and decoders with a CPU inserted between them.

23:52 Lab 2 Files, FPGA Pins, and Simulation Wrappers

The project skeleton includes `simtop.sv`, `top.sv`, and `hex_driver.sv`; the decoder implementation is completed in the provided driver file.
The FPGA board has eight hex displays, each with seven segment signals, for 56 display-control wires; the board constraint file maps signal names to physical pins.
`top` is intended for FPGA implementation, while `simtop` wraps it with testable inputs and observable outputs for simulation.

29:34 ModelSim Compilation, Waveforms, and Manual Input Forcing

Compile SystemVerilog with `vlog` before simulation; the compiled modules appear in ModelSim's `work` library.
Choose the simulated top-level module, add signals such as `A`, `B`, `C`, and `Y` to the waveform, and advance time with `run`.
Uninitialized inputs begin as `Z`, which can propagate to `X` through Boolean logic; forcing `A=1`, `B=1`, and `C=0` demonstrates the NAND-and-inverter outputs.

40:00 Building a Repeatable Test Bench with an Initial Block

A test bench has no ports and instantiates the design under test, connecting its inputs and outputs to local signals.
An `initial` block runs once at simulation startup; use `begin` and `end` when it contains multiple statements, then assign input values and insert `#` delays.
A test bench preserves stimulus across simulation restarts, avoiding repeated manual input forcing, but waveform inspection still requires checking outputs by hand.

47:27 SystemVerilog Always Blocks and Sensitivity Lists

`assign` describes continuous combinational behavior, while `always` blocks support procedural constructs such as `if`, `case`, and loops.
`always_comb` implies sensitivity to combinational inputs; `always_ff` marks clocked sequential logic and helps catch coding errors.
A clocked process responds to clock edges, while combinational logic must reevaluate when its inputs change; a plain `always` block with no sensitivity list is useful for simulation but is not synthesizable.

53:45 Combinational Muxes, Output Ownership, and Accidental Latches

A ternary `assign` and an `always_comb` block with `if/else` can both implement a 2-to-1 mux selecting between `foo` and `bar`.
Every output in a combinational `always` block must receive a value on every control path; omitting an `else` can infer a latch that retains the prior value.
Each `assign`, module output, or `always` block drives its signals, so assigning one signal from multiple independent sources can cause a driver conflict.

58:06 Default Assignments and Case Statements for Control Logic

Assigning default values at the top of an `always_comb` block ensures every output has a value, then branches can override only the signals that differ.
This default-first style is useful in a CPU control unit, where one instruction such as `ADD` can define defaults and `SUB` can override just the ALU operation.
A `case` statement selects behavior by input value; underscores in numeric constants improve readability and are ignored by SystemVerilog.

1:04:44 How Incomplete Sensitivity or Assignments Infer Memory

A clocked block such as `always @(posedge clock)` updates a register on the rising edge even when data input `B` is not in the sensitivity list.
Combinational sensitivity with incomplete output assignments also implies storage: an output must retain its previous value on paths where no new assignment occurs.
`always_comb` and complete defaults help reveal or prevent unintended storage in combinational logic.

1:06:44 Latch Versus Flip-Flop Timing and Why Latches Are Avoided

A latch is level-sensitive: while its clock is high, `Q` follows `D`; when the clock goes low, it holds the last value.
A flip-flop is edge-triggered and samples `D` at a rising or falling clock edge, like a camera capturing a single instant.
Edge-triggered flip-flops make timing analysis more manageable; Bakos advises avoiding latches in on-chip designs because level-sensitive timing is difficult to constrain.

1:12:34 Self-Checking Test Benches and the Propagation-Delay Epsilon

A basic self-checking test bench assigns inputs, waits briefly, and uses an `if` statement plus `$display` to report an unexpected output.
RTL simulation does not model physical capacitance, resistance, or real signal propagation, but a small delay such as `#10` lets scheduled logic updates settle before checks.
The delay-based approach is an improvement over visual inspection but is less structured than clock-coordinated stimulus and checking.

1:13:07 Clocked Test-Bench Checks and Test-Vector Files

A clocked test bench can set inputs on the rising edge and check outputs on the falling edge, separating stimulus from verification.
A test-vector file records inputs alongside expected outputs so the test bench can compare results automatically.
The approach combines `initial` setup with an `always` clock process and provides a repeatable testing pattern for the FPGA labs.

1:15:04 Applying Test Benches to the FPGA Labs

Lab work benefits from a self-checking test bench that exercises decoder inputs and verifies expected segment outputs.
Simulation checks RTL behavior before FPGA deployment; if hardware behavior differs, Quartus tools and JTAG signal probing can help investigate.
