8:1 Conservation of Energy - Concepts and 1-D Equations

Overview

Derek Elsworth connects energy conversion in power systems to the control-volume first law and a practical, one-dimensional Bernoulli equation. He explains how pumps, turbines, frictional head loss, and stored elevation affect energy and power, using examples including compressed-air storage, a steam turbine, and pumped hydro.

Key takeaways

Pumped hydro stores surplus electricity as gravitational potential energy, but both the pumping cycle and the return flow incur losses, so recovered electricity is lower than the energy used to store it.
For steady flow, specific total energy combines internal energy, pressure energy, kinetic energy, and gravitational potential energy; pressure plus internal energy forms specific enthalpy.
The extended Bernoulli head balance tracks elevation, pressure, velocity, pump or turbine contribution, and frictional head loss; pump head is positive when energy enters the flow, while head loss is always nonnegative.
A rise in pipe elevation reduces pressure when velocity and other terms remain unchanged, and a large enough pressure decrease can trigger cavitation.
Hydropower’s ideal power scales with fluid density, gravity, volumetric flow rate, and elevation drop: P = ρgQH; friction and machinery inefficiency reduce real output.
In the steam-turbine example, an enthalpy decrease from 3348 to 2550 kJ/kg supplies roughly 0.8 MJ of shaft work per kilogram after accounting for the modest increase in flow kinetic energy.

Chapters

0:00 Grid Storage: Pumped Hydro and Compressed-Air Reservoirs

Pumped storage uses surplus electricity to move water from a lower reservoir to an elevated one, then generates power as water returns through a turbine.
Compressed-air energy storage puts air into a porous reservoir, such as a depleted oil field or aquifer, and later routes it through a turbine.
Both storage approaches return less energy than they consume because the system has losses.

6:00 Power Generation: Gas Turbines, Wind, and Hydroelectric Systems

A gas turbine burns fuel in compressed air; expanding hot gas turns blades connected to an electrical generator.
Combined-cycle plants can use exhaust heat to make steam and drive an additional turbine, recovering some otherwise wasted energy.
Gas turbines can respond quickly to electricity demand, unlike coal and nuclear plants, which are harder to ramp up or down.

12:00 Hydropower Examples from Iceland, China, and New Zealand

Iceland’s hydroelectric facilities illustrate turbines driving generators, while the country’s energy system also draws on geothermal resources.
China’s Jinping-I Dam, described as roughly 300 meters tall, sends water through pressure-lined tunnels to underground turbines; surge chambers help absorb pressure changes when flow is stopped.
New Zealand examples include hydroelectric generation on the Waikato River, the Arapuni power station, and the Wairakei geothermal field.

17:00 From Conservation of Mass and Momentum to Energy

Elsworth reviews the course’s conservation-law framework: mass is the extensive property for continuity, and momentum is mass times velocity.
The momentum discussion links linear flow to rotation, as in a sprinkler, by accounting for forces and rotational effects.
For energy, the extensive property is total energy and the corresponding specific property is energy per unit mass.

18:00 Specific Energy: Internal, Pressure, Kinetic, and Elevation Terms

The specific energy expression is internal energy plus pressure divided by density, velocity squared over two, and gravitational potential energy g z.
Each term has units of joules per kilogram; the kinetic term V²/2 is energy per unit mass despite appearing as a velocity squared.
Pressure and internal energy are grouped as specific enthalpy, h = u + p/ρ, which is useful for fluids undergoing heating or phase change.

22:00 The Control-Volume First Law and Energy-Flow Sign Convention

Substituting specific energy into the Reynolds transport theorem yields a steady-flow first-law balance between inlet and outlet energy, heat transfer, and work.
Mass flow rate multiplied by specific energy gives a power rate in watts; shaft work entering the system is positive, while turbine work extracted is negative.
The balance includes enthalpy, kinetic energy, and elevation energy, making it suitable for turbines handling hot or pressurized fluids.

26:00 Extended Bernoulli Equation: Pump Head and Head Loss

For steady, one-dimensional flow, the head balance includes elevation z, pressure head p/γ, velocity head V²/(2g), pump head Hₚ, and head loss Hₗ.
Pump head adds energy to the flow; a turbine can be represented by a negative pump-head contribution, while head loss is nonnegative.
The velocity-profile correction factor α accounts for nonuniform velocity distributions, though Elsworth says it is often omitted in the course’s applications.

29:00 Hydraulic Grade Lines, Pipe Elevation, and Cavitation

The hydraulic grade line represents z + p/γ, while the energy grade line also includes velocity head; a pump raises the energy grade and friction lowers it.
In a constant-diameter pipe, continuity keeps the mean speed constant, so a rise in elevation must be offset by a pressure decrease when other terms are unchanged.
A sufficiently large pressure drop can cause cavitation; Elsworth uses an elevation scale of about 10 meters (30 feet) as the approximate atmospheric-pressure head.

37:00 Steam-Turbine Example: Converting Enthalpy Drop into Work

The worked turbine example uses an inlet speed of 30 m/s and enthalpy of 3348 kJ/kg, with outlet speed of 60 m/s and enthalpy of 2550 kJ/kg.
With equal inlet and outlet elevations and no heat transfer, the enthalpy decrease and small kinetic-energy change become shaft work; the result is about 0.8 MJ/kg.
Multiplying work per unit mass by mass flow rate gives turbine power, expressed in joules per second or watts.

43:00 Pumped-Storage Efficiency and Hydropower Power Calculations

For large reservoirs, inlet and outlet velocities are treated as approximately zero and both free surfaces are at atmospheric pressure, simplifying the head balance.
Generating power as water descends yields less energy than the ideal elevation drop because pipe friction and turbine inefficiency consume head.
Pumping water uphill requires input to overcome both the elevation gain and friction; a useful ideal power relation is P = ρgQH, with actual output reduced by losses.
The lecture closes by emphasizing upstream-to-downstream sign discipline and reserving the first-law enthalpy form for cases such as phase-changing turbine flows.
