EM fields lecture 22 - relation of electrical energy and potential and energy of charge arrangements

Overview

Electrical potential is given a physical interpretation as energy change per unit charge, building on the path independence of work by conservative electrical forces. The lecture derives three equivalent ways to calculate the energy of point-charge arrangements, then checks them on a four-ion sodium chloride square, whose energy is approximately −2.59kQ²/A.

Key takeaways

For a conservative electric force, ΔU = −∫F·ds and Δφ = −∫E·ds, so potential difference equals energy change per unit charge: Δφ = ΔU/q.
The energy of N point charges is U = k∑ᵢ<ⱼQᵢQⱼ/Rᵢⱼ, with each distinct pair counted once and k = 1/(4πε₀).
The equivalent formula U = ½∑ᵢQᵢφᵢ uses the potential at each charge due to all other charges; the factor ½ corrects for counting every interaction from both endpoints.
In the alternating four-ion square, four attractive edge interactions contribute −4kQ²/A, while two repulsive diagonal interactions contribute √2kQ²/A, giving U ≈ −2.59kQ²/A.
An arrangement’s total energy can be calculated by tracking assembly work, summing distinct pair interactions, or summing charge times local potential with a factor of one-half.

Chapters

0:00 Conservative Forces Link Work to Potential Energy

Electrical and gravitational forces are conservative, so the work they do moving a charge or mass from A to B does not depend on the path.
For conservative forces, the change in potential energy is the negative work done by the force: ΔU = −∫F·ds.
Potential energy plus kinetic energy is conserved for systems acted on by conservative forces.

3:35 Field Lines, Equipotentials, and Moving a Test Charge

The sketch pairs black electric-field lines with blue constant-potential contours, which meet at right angles.
Moving a test charge between points A and B can be represented as many small path elements, ds.
Because the electrical force is conservative, every path from A to B gives the same work and energy transfer.

8:00 Deriving Potential as Energy per Unit Charge

Dividing the work-energy relation by the test charge turns force per unit charge into the electric field, E = F/q.
The negative line integral of E between two points gives the potential difference, Δφ = −∫E·ds.
Combining these relations gives Δφ = ΔU/q: potential difference is the change in electrical energy per unit charge.

13:20 Building a Charge Arrangement One Charge at a Time

The energy stored in a point-charge arrangement can be found by calculating the work required to bring its charges in from far away.
The first charge costs no assembly energy when the initially empty space is assigned zero potential.
Each later charge contributes its charge multiplied by the potential created at its destination by charges already assembled.

17:50 Three Charges Produce Three Pairwise Energy Terms

For charges Q₁, Q₂, and Q₃, bringing in Q₂ contributes kQ₁Q₂/R₁₂, where k = 1/(4πε₀).
Bringing in Q₃ contributes two terms, kQ₁Q₃/R₁₃ and kQ₂Q₃/R₂₃, because both earlier charges create potential at its location.
Adding the assembly contributions gives one energy term for each distinct pair: (1,2), (1,3), and (2,3).

23:00 General Pairwise Formula for Point-Charge Energy

For N point charges, total energy is U = k∑ᵢ<ⱼ QᵢQⱼ/Rᵢⱼ, summing over distinct pairs only once.
The sign of each term follows the charge product: like-sign pairs contribute positive energy and opposite-sign pairs negative energy.
Summing distinct pairs is direct for small arrangements, but becomes cumbersome as the number of charges grows.

27:30 Rewriting the Energy as Half the Charge-Potential Sum

A double sum over charge indices i and j counts each interaction twice, once as (i,j) and again as (j,i).
The factor of one-half corrects this double counting, while self-interactions with i = j are excluded.
Recognizing the sum over other charges as the potential at charge i gives U = ½∑ᵢQᵢφᵢ, with each φᵢ excluding that charge’s own potential.

37:00 Four-Ion Sodium Chloride Square and Its Geometry

The example is a square arrangement of four ions, with two positive and two negative charges alternating at the corners.
Adjacent, opposite-sign ions are separated by A; like-sign ions across the diagonals are separated by √2A.
The shorter attractive interactions outweigh the longer repulsive interactions, making the total electrostatic energy negative.

41:30 Calculating the Crystal Energy with Potentials

At each corner, the potential is the sum of contributions from the other three ions, using distances A and √2A.
By square symmetry, each ion has the same potential pattern; multiplying each charge by its local potential and applying the one-half factor avoids double counting.
The resulting crystal energy is approximately −2.59kQ²/A, where k = 1/(4πε₀).

49:00 Checking the Crystal Energy by Summing Six Pairs

The square has six distinct interacting pairs: four opposite-sign edge pairs at distance A and two like-sign diagonal pairs at distance √2A.
The pair sum is kQ²/A(−4 + 2/√2), which is approximately −2.59kQ²/A.
The matching pair-sum and charge-potential results confirm that both formulas calculate the same stored interaction energy.
