ME2120 - Dynamics

Overview

Professor Ryan C. Cooper develops the equations of motion for a spring-supported cube by choosing a two-degree-of-freedom model and defining its position, velocity, and acceleration. He then connects those kinematics to a kinetic diagram and spring-force free-body diagram, yielding separate Cartesian equations, m ẍ = -kₓx and m ÿ = -kᵧy, while noting that gravity can be included if needed.

Key takeaways

Use the number of independent measurements needed for the engineering question to choose degrees of freedom; a 3D trajectory can still need only one coordinate if a track fixes the path.
For a two-coordinate cube model, x(t) and y(t) fully define position, velocity, and acceleration through differentiation, without requiring numerical values first.
In polar coordinates, acceleration is (r̈ - rθ̇²)eᵣ + (rθ̈ + 2ṙθ̇)eθ, separating radial and transverse effects.
A linear spring force depends on displacement and restores toward equilibrium: Fₓ = -kₓx, leading to m ẍ = -kₓx.
Use separate stiffness constants for perpendicular directions when the spring or supporting structure is directionally different; the x and y responses need not match.
A free-body diagram can omit gravity when it is negligible for the motion being modeled, but gravity can be added explicitly when it matters.

Chapters

0:00 Case Problem 3: Choosing the Model's Degrees of Freedom

Cooper resumes the spring-and-cube case problem, where the goal is to predict how the system moves.
He argues that two degrees of freedom, left-right and up-down motion, capture the measurements of interest without modeling every possible 3D motion.
A fully unconstrained rigid body in 3D has six degrees of freedom: three position coordinates and pitch, roll, and yaw.

6:00 Spring Bending, Constraints, and the Two-Coordinate Approximation

If the spring's length is fixed, the cube's vertical position can depend on its other coordinates, reducing the number of independent variables.
Cooper contrasts a spring's relatively low bending stiffness with its much greater axial stiffness, explaining why sideways deflection may dominate.
A roller coaster illustrates how motion through 3D space can still have one degree of freedom when its position is fixed by distance along a track.

12:00 Selecting an Origin and Defining Cartesian Position

The class considers possible coordinate origins, including the spring attachment and the cube's center.
Choosing the cube's center makes the equilibrium position correspond to x = 0 and y = 0, simplifying the model.
Coordinates are meaningful only after specifying their reference origin; x and y describe the cube's position relative to that choice.

18:00 Cartesian Velocity and Acceleration from Position

With fixed Cartesian unit vectors, position is r = x i + y j, so velocity is v = ẋ i + ẏ j.
Differentiating each coordinate again gives acceleration a = ẍ i + ÿ j.
Because i and j do not change direction in the chosen frame, their derivatives are zero.

23:00 Polar Coordinates and the Radial and Transverse Acceleration Terms

Polar position is r eᵣ, with radius r and angle θ; θ is an angle, not a distance measurement.
The radial unit vector is eᵣ = cos θ i + sin θ j, and eθ is perpendicular to it in the direction of increasing θ.
Polar velocity has radial and transverse components: ṙ eᵣ + r θ̇ eθ.
Polar acceleration includes radial acceleration r̈ - r θ̇² and transverse acceleration r θ̈ + 2ṙθ̇; the r θ̇² contribution is associated with centripetal acceleration.

29:00 Why Kinematics Are Complete Before Solving for Motion

Once x(t) and y(t) are defined, they determine the cube's position, velocity, and acceleration even before their numerical values are known.
The next task is to identify the forces that change those coordinates and use them to solve for the time-dependent motion.
Cooper frames kinematics as a set of precise definitions, not a numerical answer: acceleration can be integrated to recover velocity and position.

35:00 Drawing the Kinetic Diagram and Spring Free-Body Diagram

The kinetic diagram represents m a, using the acceleration definition already established: ẍ i + ÿ j.
The kinetic diagram is not a prediction of acceleration at one particular location; it records the general acceleration components for the model.
The free-body diagram identifies the spring forces, while gravity may be omitted for the small, rapidly moving system or added as a downward force if desired.

41:00 Hooke's Law Produces Separate X and Y Equations

The x-direction spring force depends on displacement, not speed or acceleration, and is written Fₓ = -kₓx.
The negative sign makes the spring force restorative: positive x produces negative force, and negative x produces positive force.
Matching force and acceleration components gives m ẍ = -kₓx; the y direction similarly gives m ÿ = -kᵧy.
The x and y stiffnesses can differ for an anisotropic structure, such as a beam that bends more easily in one direction.

46:00 Equations of Motion and Preparation for Solving Them

The derivation's output is a pair of differential equations describing the cube's motion in the x and y directions.
Cooper identifies solving these equations of motion as the next step in the module.
Suggested background examples include Cartesian-coordinate problems, satellite tracking, and a particle moving on a hemisphere.
