EM fields lecture 20 - arrangements of charged conductors and coefficients of potential p_ij

Overview

The lecture analyzes a charged conducting sphere of radius A inside a concentric conducting shell with radii B and C, deriving the charge distribution, electric field, and potentials in each region. It then introduces geometry-dependent potential coefficients, using the sphere-shell results to obtain a symmetric 2×2 coefficient matrix that maps arbitrary conductor charges to their potentials.

Key takeaways

For a sphere of charge Q1 inside a concentric shell of net charge Q2, the shell's inner surface carries −Q1 and its outer surface carries Q1 + Q2.
The electric field is zero inside either conductor, equals Q1/(4πε0r²) in the gap, and equals (Q1 + Q2)/(4πε0r²) outside the shell.
With potential zero at infinity, the inner sphere's potential is φ1 = Q1/(4πε0)(1/A + 1/C − 1/B) + Q2/(4πε0C).
Potential coefficients encode geometry: φi = Σj PijQj, and electrostatic reciprocity makes the coefficient matrix symmetric, Pij = Pji.
For the concentric sphere-shell arrangement, the three independent coefficients are P11 = (1/A + 1/C − 1/B)/(4πε0) and P12 = P21 = P22 = 1/(4πε0C).
An isolated conducting sphere has self-capacitance 4πε0A, the reciprocal of its potential coefficient 1/(4πε0A).

Chapters

0:00 Define the Concentric Sphere–Shell Geometry

Conductor 1 is a conducting sphere of radius A carrying charge Q1.
Conductor 2 is a concentric conducting shell with inner radius B, outer radius C, and total charge Q2.
The analysis divides space into the sphere interior, the A-to-B gap, the shell metal, and the exterior.

3:45 Determine the Electric Field in All Four Regions

Electrostatic equilibrium makes the field zero inside the sphere and within the conducting shell.
Between radii A and B, the radial field is E = Q1/(4πε0r²), as if the sphere's charge were at the center.
Outside radius C, the field is E = (Q1 + Q2)/(4πε0r²), set by the total enclosed charge.

7:05 Use Gauss’s Law to Fix the Surface Charges

Spherical symmetry distributes the sphere's Q1 uniformly over its surface area 4πA².
The shell's inner surface carries −Q1 so the field within the shell metal remains zero.
The shell's outer surface carries Q1 + Q2, leaving the shell's net charge equal to Q2.

10:07 Integrate the Exterior Field to Find the Shell Potential

The zero of potential is chosen at infinity, the standard reference for a finite charge distribution.
Integrating the exterior field from infinity to r = C gives the shell potential φ2 = (Q1 + Q2)/(4πε0C).
Because the electric field is zero in the shell metal, its entire thickness is at the same potential.

18:11 Find the Sphere-to-Shell Potential Difference

The potential difference φ1 − φ2 comes from integrating the field through the gap from B to A.
Only Q1 contributes to the gap field, giving φ1 − φ2 = Q1/(4πε0)(1/A − 1/B).
The potential is constant inside each conductor and varies as 1/r in the charge-free radial regions.

24:23 Combine Contributions to Obtain the Inner-Sphere Potential

Adding φ2 to φ1 − φ2 gives φ1 = Q1/(4πε0)(1/A + 1/C − 1/B) + Q2/(4πε0C).
The potential on the sphere depends on both conductor charges, even when the sphere itself has no charge.
Setting Q1 or Q2 to zero isolates each conductor's contribution; setting both to zero gives zero potential relative to infinity.

29:33 Introduce Potential Coefficients for Coupled Conductors

For two conductors, potentials are linear in charge: φ1 = P11Q1 + P12Q2 and φ2 = P21Q1 + P22Q2.
The off-diagonal coefficients are equal, P12 = P21, leaving three independent coefficients for two conductors.
The coefficients depend on conductor geometry, not on the particular charges or resulting potentials.

36:23 Calculate the Self-Coefficient of an Isolated Sphere

An isolated sphere of radius A has potential φ1 = Q1/(4πε0A).
Comparing this with φ1 = P11Q1 gives P11 = 1/(4πε0A), the sphere's potential coefficient.
The corresponding self-capacitance is its reciprocal: Cself = 4πε0A.

40:32 Extract Sphere–Shell Coefficients from Two Special Cases

With Q1 = 0, both conductors have potential Q2/(4πε0C), yielding P12 = P21 = 1/(4πε0C) and P22 = 1/(4πε0C).
With Q2 = 0, the sphere potential gives P11 = 1/(4πε0)(1/A + 1/C − 1/B).
The two special charge configurations recover all three independent coefficients for this geometry.

48:40 Assemble the Symmetric Potential-Coefficient Matrix

The matrix is P = (1/(4πε0)) [[1/A + 1/C − 1/B, 1/C], [1/C, 1/C]].
Multiplying this matrix by the charge vector (Q1, Q2)ᵀ gives the potentials (φ1, φ2)ᵀ for any charge values.
Once the geometry-dependent coefficients are known, potentials can be calculated without re-solving the field for each new charge arrangement.
