Lecture 2 of Medical Physics 537, Human Physiology and Anatomy, with course instructor Marty Pagel

Overview

Marty Pagel explains how concentration gradients, electrical forces, and ion-specific membrane permeability determine equilibrium and resting membrane potentials, then applies those principles to motor-neuron action potentials. The lecture covers sodium and potassium channel gating, approximate 2 ms absolute and 4 ms relative refractory periods, and concludes with skeletal anatomy terms students should learn to label.

Key takeaways

The Nernst equation predicts the equilibrium potential for one ion from its concentration ratio and charge; sodium's outside-high gradient gives a positive equilibrium potential, while chloride's negative charge produces a negative one.
A cell's membrane potential reflects the relative permeabilities of sodium, potassium, and chloride, so a highly permeable ion contributes more strongly to the combined potential.
At a nerve-cell resting potential near -85 mV, sodium is driven inward by both its concentration gradient and electrical attraction, while potassium's outward concentration drive is partly counteracted by electrical attraction inward.
Action-potential timing depends on distinct channel gates: sodium activation produces rapid inward current, sodium inactivation stops it, and delayed potassium activation supports outward current and recovery.
The lecture gives approximate refractory periods of 2 ms absolute and 4 ms relative, explaining why a neuron cannot immediately repeat an action potential and then needs a stronger stimulus for a short time.
Skeletal anatomy review includes identifying major bones such as the frontal bone, maxilla, ulna, and radius, alongside developmental differences between infant and adult proportions.

Chapters

0:00 Nernst Equilibrium Potentials for Sodium, Potassium, and Chloride

Ion flux reflects both diffusion down a concentration gradient and electrical forces acting on charged particles.
The Nernst equation relates an ion's equilibrium potential to its inside-to-outside concentration ratio and charge.
Sodium and chloride are concentrated outside cells, while potassium is concentrated inside; the lecture gives approximate equilibrium potentials of +66.6 mV for sodium and -80 mV for chloride.

8:00 How Ion Permeability and Conductance Combine Membrane Currents

The combined membrane potential depends on sodium, potassium, and chloride concentrations, with each ion weighted by its membrane permeability.
Chloride's negative charge reverses its concentration ratio's direction in the combined equation.
Current follows I = G × E: conductance and the potential difference from an ion's equilibrium potential determine ion-specific current.

15:07 Electrochemical Forces at a Nerve Cell's -85 mV Resting Potential

At the stated nerve-cell resting potential of about -85 mV, sodium's concentration and electrical gradients both drive positively charged ions into the cell.
Potassium's concentration gradient favors outward movement, while the negative cell interior electrically attracts potassium inward, opposing that movement.
The direction and strength of ion flux depend on the balance between diffusion and electrical force, not concentration alone.

18:22 Motor-Neuron Stimulation, Threshold, and Refractory Periods

A motor neuron includes a soma, dendrites, a long axon, and axon terminals; Schwann cells produce the myelin sheath around much of the axon.
Electrical stimulation depolarizes or hyperpolarizes the membrane, and the voltage response develops over a finite time rather than instantaneously.
Pagel describes an approximately 2 ms absolute refractory period, followed by a relative refractory period of about 4 ms, during which another action potential is harder to trigger.

23:44 Voltage-Gated Sodium and Potassium Channels Shape the Action Potential

Opening sodium-channel activation gates causes a rapid inward sodium current; sodium inactivation gates then shut off that influx.
Potassium-channel activation opens later, allowing potassium to flow outward and help return the membrane toward its resting state.
The sodium channel also has an ion-selectivity filter and toxin-binding sites; the lecture cites shellfish and scorpion toxins as blockers that can prevent signaling.

28:13 Skeletal Development and the Bones Students Should Identify

Comparing a six-foot baby with a six-foot adult illustrates developmental changes, including a proportionally large infant skull and smaller limb bones.
Students are asked to label major skeletal structures, including the frontal bone, temporal bone, maxilla, ulna, and radius.
The anatomy slides continue through the hands, pelvis, and feet, emphasizing practice with the assigned skeletal-system terms.

Summary, takeaways, and chapters were generated by AI from the video's transcript and may contain errors. The video belongs to its creator, Marty Pagel.
