ECE344 Fall 2026 (Sec 1) Lec 7 - Advanced IPC

Overview

Jon Eyolfson explains how Unix pipes, file descriptors, fork, dup2, and exec combine to support interprocess communication and shell-style redirection. He emphasizes that closing unused pipe ends is essential for EOF and termination, then shows how close-on-exec flags both prevent descriptor leaks and enable reliable detection of exec failures.

Key takeaways

A pipe’s read end reaches EOF only after its buffer is empty and every process has closed every descriptor referring to the write end.
After fork(), parent and child have separate descriptor tables, but inherited descriptors can still refer to the same kernel pipe.
dup2 is the core mechanism behind shell redirection: it makes standard input or output refer to a chosen file or pipe endpoint before exec.
exec replaces a process’s program memory but normally preserves its open file descriptors, so unused descriptors must be closed or marked close-on-exec.
A close-on-exec pipe provides an unambiguous exec-status channel: EOF means exec succeeded, while an error payload means it failed.

Chapters

0:00 Reviewing Shell Redirection and File Descriptors

A shell typically calls fork, configures the child’s file descriptors, then uses execve to run a program.
Input redirection makes file descriptor 0 refer to a file before the program starts.
Lab 2’s suggested weekly schedule is flexible; the more confusing week 2 material follows this lecture.

3:00 The pipe System Call Creates a One-Way Byte Channel

pipe() takes space for two integers and stores the read-end descriptor at index 0 and write-end descriptor at index 1.
The kernel manages a shared byte buffer: read consumes bytes in order, and write appends bytes.
A read blocks while the buffer is empty; a write blocks when it is full. Linux pipes are typically 64 KiB, though that size need not be memorized.

6:15 Using fork to Send a Message Between Processes

Calling pipe() before fork() gives both parent and child descriptors referring to the same kernel pipe.
In the example, the parent closes its read end and writes “Hello from parent”; the child closes its write end and reads the message.
After fork(), the processes have independent descriptor tables, but corresponding descriptors still refer to the shared pipe resource.

11:00 Pipe EOF Requires Every Write End to Be Closed

read() returns 0 after buffered data is drained only when no process has the pipe’s write end open.
Leaving the parent’s write descriptor open keeps the child blocked in read(), while the parent may be blocked in wait().
Close unused pipe ends immediately after fork(); process termination closes remaining descriptors, but explicit cleanup is better practice.

20:00 dup2 Connects Pipe Ends to Standard Input and Output

dup2(oldfd, newfd) makes newfd refer to the same kernel resource as oldfd, closing newfd first if it was already open.
A shell implements redirection by opening a file and using dup2 to replace descriptor 0 or 1.
For a pipeline, dup2 can connect one process’s standard output to the pipe’s write end and another process’s standard input to its read end.

26:48 Running tr Through a Pipe and Avoiding Inherited Write Ends

The child redirects descriptor 0 to the pipe’s read end, closes the original pipe descriptors, and execs tr to uppercase incoming text.
The parent writes its message to the pipe and closes the write end so tr can observe EOF and terminate.
If the child leaves a pipe write descriptor open, exec does not close it by default; tr can then wait forever for input that will never arrive.

34:13 Inspecting Leaked Descriptors and Setting Close-on-Exec

On Linux, /proc can show a process’s open descriptors and whether they refer to a pipe’s read or write end.
A useful exec convention is to leave the new program only descriptors 0, 1, and 2, connected to the intended resources.
The close-on-exec flag automatically closes a descriptor during exec; pipe2 can create pipe descriptors with this flag set.

39:00 Close-on-Exec Flags and the Ambiguity of Exit Status

Without extra communication, a parent cannot distinguish an exec failure from a successfully executed program that exits with the same status.
Close-on-exec applies to individual descriptor numbers, not generally to every descriptor referring to the same resource.
When dup2 duplicates a descriptor onto standard input or output, the target descriptor can remain open across exec while the original close-on-exec descriptors are closed.

43:13 Reporting exec Failures Through a Close-on-Exec Pipe

Create a pipe with close-on-exec enabled before fork(); if the child’s exec succeeds, the kernel closes its pipe descriptors automatically.
If exec fails, the child still has the pipe and can write the error number before exiting.
The parent closes its write end and reads: EOF indicates successful exec, while received error data indicates failure, such as a missing executable.
