Electronegativity, Polar Bonds, Lewis Symbols and Formal Charges

Overview

John Flood Chemistry connects ionic, covalent, hydrogen, and metallic bonding to electron behavior, emphasizing that ionic compounds form extended lattices while molecular compounds are discrete units. The lesson develops bond polarity through electronegativity trends, the 0.4 and 1.9 classification thresholds, and atomic size, then applies Lewis symbols, octet and duet rules, common bonding patterns, and formal-charge calculations.

Key takeaways

Ionic compounds such as NaCl form continuous lattices of cations and anions, whereas molecular compounds such as H2O consist of discrete covalent units.
Electronegativity generally increases upward and to the right on the periodic table, with fluorine assigned 4.0; bond differences of 0.4 or less are conventionally nonpolar covalent, while differences of 1.9 or more are conventionally ionic.
Bond polarity depends on both electronegativity and atomic size: carbon and iodine can have similar electronegativities, yet shared electrons spend more time around the larger iodine atom.
Lewis structures count shared electron pairs for both atoms: N2 requires a triple bond, O2 a double bond, and Cl2 a single bond to satisfy octet patterns.
Formal charge is calculated for each atom using valence electrons minus nonbonding electrons minus bond lines, or equivalently valence electrons minus dots minus lines.
Polyatomic ionic compounds contain two bonding regimes simultaneously: ionic attraction between charged polyatomic ions and covalent bonds within each ion.

Chapters

0:00 Reviewing Ionic Compounds and Polyatomic-Ion Charges

Ionic compounds can contain a metal and nonmetal, a metal and polyatomic ion, a polyatomic ion and nonmetal, or two polyatomic ions.
Sulfate, SO4^2−, must be treated as one polyatomic unit rather than as separate sulfur and oxygen ions.
FeSO4 contains Fe^2+ because the sulfate ion contributes a 2− charge; iron must balance it with a 2+ charge.
Ammonium chloride illustrates that NH4+ is a single polyatomic ion, not nitrogen plus four independent hydrogens.

5:00 Unit 4 Introduces Models of Chemical Structure

John Flood Chemistry distinguishes useful models from complete descriptions: the Bohr model helps explain electron transitions, while Lewis structures depict molecular connectivity.
Unit 4 shifts from atomic properties and compound classification toward how atoms are held together.
Lewis structures are useful for representing discrete molecules but are not a complete explanation of why atoms bond or react.

10:00 Defining Chemical Bonding and Its Major Types

Chemical bonding is defined as an attractive force holding two or more atoms together.
Ionic bonding forms through transfer of valence electrons, as in sodium reacting with chlorine to produce sodium chloride.
Covalent bonding forms through sharing valence electrons, as illustrated by the shared electrons in H2O.
Hydrogen bonding is much weaker than covalent bonding, while metallic bonding involves valence electrons delocalized across many metal atoms.

15:00 Ionic Versus Covalent Bonding in Dissolution

Ionic compounds contain permanent cation–anion attractions, whereas covalent molecules retain their internal bonds when dissolved.
Water can separate Na+ and Cl− ions from sodium chloride because water molecules interact strongly with the ions.
Dissolving sugar separates individual sugar molecules from one another without breaking the C–H, C–O, or other covalent bonds inside each molecule.
Ionic bonds and covalent bonds differ not only in strength but also in the mechanisms by which they can be disrupted.

20:00 Molecules, Compounds, and Extended Ionic Lattices

A compound requires atoms from at least two different elements; a molecule requires at least two atoms but may contain only one element, such as O2.
Molecular compounds contain two or more elements connected by shared electrons, while ionic compounds contain oppositely charged ions.
Sodium chloride forms an extended three-dimensional lattice with no discrete beginning or end.
Molecules such as H2O are discrete units with identifiable boundaries, so the term ionic molecule is not used for lattice-based ionic compounds.

25:00 Why Covalent Bonds Form Between Nonmetals

Covalent bonds generally form between atoms with similar ionization energies and electron affinities, especially nonmetals.
H2 forms when two neutral hydrogen atoms share their one valence electron each.
A coefficient describes multiple particles, whereas a subscript describes the number of atoms within one molecule; 2H represents two hydrogen atoms, while H2 represents one hydrogen molecule.
Covalent bonding changes separate atoms into a discrete molecule without changing the nuclei.

30:00 Bond-Length Energy Wells and Molecular Stability

An energy-versus-bond-length diagram for H2 has a minimum at the preferred distance between the two hydrogen nuclei.
Pushing nuclei closer produces repulsion, while separating them too far removes the stabilizing attraction.
A bond behaves like a spring: molecular vibrations continually compress and extend the bond around its equilibrium length.
Helium atoms do not form a stable bond; their energy curve remains essentially flat rather than producing an energy well.

35:00 Bond Formation, Bond Breaking, and Enthalpy

Bond formation lowers the system's energy and is exothermic, while bond breaking requires energy and is endothermic.
Ultraviolet radiation can break ozone, O3, into O2 and O by supplying the required bond energy.
A negative enthalpy change, such as ΔH = −1200 kJ, indicates that the system released energy and that bond formation contributed to the process.
John Flood Chemistry corrects an in-class verbal slip and reinforces that bonds form with energy release rather than energy absorption.

40:00 Bond Polarity as Unequal Electron Sharing

A polar bond has unequal electron sharing, producing a region of higher electron density with partial negative character and a lower-density region with partial positive character.
Partial charges are written as δ− and δ+, not as full ionic charges.
A dipole arrow points toward the electron-rich, partially negative atom; the crossed end identifies the partially positive side.
Polarity concerns electron-density distribution within a bond, not simply whether a compound contains polar atoms.

45:00 Electronegativity Trends Across the Periodic Table

Electronegativity measures an atom's tendency to pull shared electrons toward itself.
Electronegativity generally increases upward within a group and from left to right across a period.
Fluorine is assigned the highest common value, 4.0, and is more electronegative than chlorine, bromine, or iodine.
Noble gases such as helium, neon, and argon typically lack assigned electronegativity values in introductory chemistry.

50:00 Electronegativity Difference and Bond Classification

A difference in electronegativity of 0 corresponds to a pure nonpolar bond, typically between identical atoms such as H–H, O–O, or Cl–Cl.
Differences of 0.4 or less are conventionally labeled nonpolar covalent, even though weak partial charges may still exist.
Differences of 1.9 or greater are conventionally labeled ionic because electron transfer dominates over covalent sharing.
The C–H bond has an approximate difference of 0.4 and is classified as nonpolar covalent, while C–N at about 0.5 is classified as polar covalent.

55:00 Atomic Size Adds Polarity Beyond Electronegativity

Electronegativity difference is not the only determinant of polarity; differences in atomic size can shift electron density.
Carbon and iodine can have similar tabulated electronegativities, yet the larger iodine atom provides more space where shared electrons are likely to be found.
The C–I bond therefore has partial negative character on iodine despite the apparent electronegativity tie.
A rigorous polarity analysis considers both electronegativity differences for similarly sized atoms and size differences for atoms with similar electronegativities.

1:00:00 Using Bond Identity to Predict Dipoles

Pure nonpolar bonds include C–C, O–O, H–H, N–N, F–F, Cl–Cl, Br–Br, and I–I.
John Flood Chemistry gives a practical shortcut: identical-element bonds are pure nonpolar, C–H is conventionally nonpolar, and most other common bonds are polar.
Increasing the bond order does not change the direction of polarity; a C=N double bond is polarized toward nitrogen just as a C–N single bond is.
The size of the partial charges grows qualitatively with the strength of the electron-density imbalance.

1:05:00 Comparing Partial Charges in C–H, N–H, and O–H

C–H is labeled nonpolar but can still be represented with very small partial charges because carbon and hydrogen do not have identical electronegativities.
In N–H, the dipole points toward nitrogen, giving nitrogen δ− and hydrogen δ+.
In O–H, the larger electronegativity difference produces stronger partial charges with oxygen δ− and hydrogen δ+.
Dipole arrows may point either direction on a page; orientation depends on how the bond is drawn, not on a fixed left-right convention.

1:10:00 Ranking Electronegativity Across Unequal Periodic-Table Positions

Ranking elements along diagonals is less reliable than comparing members of the same row or group.
Examples discussed include sodium and aluminum as relatively low-electronegativity elements and fluorine as the highest.
Hydrogen can be slightly more electronegative than boron, while nitrogen and chlorine may have similar tabulated values but differ in size.
Published electronegativity tables can disagree slightly, so introductory classification should emphasize periodic trends and bond identity rather than excessive numerical precision.

1:15:00 Polyatomic Ionic Compounds Contain Both Bond Types

A compound containing polyatomic ions has ionic bonding between the ions and covalent bonding within each ion.
In ammonium sulfate, NH4+ and SO4^2− attract ionically, while N–H and S–O connections are covalent.
A polyatomic ion can carry a net charge because its total proton count differs from its total electron count even though its internal atoms share electrons.
NH4+ has one fewer electron than its protons, while sulfate has two more electrons than its protons.

1:20:00 Constructing Lewis Symbols from Valence Electrons

Lewis symbols place an element's valence electrons as dots around its chemical symbol.
Dots are initially placed singly on the four sides of the symbol before additional electrons are paired.
Main-group periodic-table positions provide the valence-electron count; transition metals were not included in the exercise.
Halogens have seven valence electrons, oxygen and sulfur have six, nitrogen and phosphorus have five, and magnesium has two.

1:25:00 Turning Shared Electron Pairs into Covalent Bonds

A line in a Lewis structure represents one shared pair, or two electrons, between atoms.
H2 forms when the single electron from each hydrogen is shared as one H–H bond.
Most main-group atoms bond toward an octet of eight valence electrons, while hydrogen follows the duet rule because its first shell contains only a 1s orbital.
Shared electrons are counted for both bonded atoms when evaluating whether each atom reaches an octet.

1:30:00 Lewis Structures for N2, O2, and Cl2

N2 requires a triple bond so each nitrogen reaches eight electrons while retaining one lone pair.
O2 forms a double bond and each oxygen retains two lone pairs.
Cl2 forms a single bond and each chlorine retains three lone pairs.
Common neutral bonding patterns emerge from octet completion: nitrogen commonly forms three bonds, oxygen two, and halogens one.

1:35:00 Formal Charge Identifies Atom-Level Electron Imbalance

Formal charge is assigned to an individual atom, not merely to an entire polyatomic ion.
Using the Lewis-structure shortcut, formal charge equals valence electrons minus all nonbonding dots minus all bond lines touching that atom.
The equivalent equation is valence electrons − nonbonding electrons − one-half of bonding electrons.
For oxygen with six valence electrons, four nonbonding electrons, and two bond lines, the formal charge is 6 − 4 − 2 = 0.

1:42:30 Predicting Lone Pairs from Common Formal-Charge Patterns

Carbon with three bonds and no lone pairs has a +1 formal charge: 4 − 3 = +1.
Nitrogen with four bonds and no lone pairs has a +1 formal charge: 5 − 4 = +1.
Oxygen with three bonds and one lone pair has a +1 formal charge: 6 − 2 − 3 = +1.
A halogen with two bonds and two lone pairs has a +1 formal charge: 7 − 4 − 2 = +1; students were assigned practice adding lone pairs and charges to central atoms.
