Electron Energies and Intro to Electron Orbtials

Overview

John Flood Chemistry connects Planck’s photon-energy relationship to Bohr’s quantized electron energy levels, showing how absorption, emission, and line spectra arise from transitions between allowed states. The lesson then shifts to quantum mechanics: matter’s wave behavior, electron probability density, and three-dimensional orbitals, while practicing transition calculations and acknowledging a flawed hydrogen-wavelength exercise.

Key takeaways

Bohr’s hydrogen energy levels follow Eₙ = −2.18 × 10⁻¹⁸ J/n²; higher n levels approach zero energy and become progressively closer together.
For any electron transition, calculate ΔE using final minus initial; absorption gives positive electron ΔE, emission gives negative ΔE, and photon energy is |ΔE|.
A photon’s energy is E = hc/λ, so shorter wavelengths correspond to higher-energy photons; the hydrogen n = 4 to 1 transition emits ultraviolet light near 97 nm.
Line spectra arise because atoms absorb and emit only wavelengths matching allowed electron transitions; optical emission spectroscopy uses those wavelengths to identify elements and light intensity to estimate their amounts.
Quantum orbitals are three-dimensional probability distributions derived from |ψ|², not planetary trajectories; nodes are regions where electron probability density is zero.

Chapters

0:00 Unit Test Results and Targeted Review Appointments

Online and in-person sections both averaged 77% on the Unit 1–2 test, an unusually exact match.
Students spent about an hour on the test on average; the online scores clustered more tightly around the mean.
John Flood recommends 10–15-minute meetings to turn missed questions into concepts to study, rather than simply repeating answers.

2:00 How to Review a Test That Students Cannot Keep

Students cannot see or copy the test’s correct answers, so John Flood offers individual review in person or over Zoom.
Students can request alternate meeting times through Canvas if the posted office hours do not work.
The review focuses on identifying misunderstood concepts while respecting the restriction against photographing or recording test questions.

4:22 Planck’s Constant and the Photoelectric Effect

The speed of light, c, should be memorized; using 2.998 × 10⁸ m/s gives more precision than rounding to 3.0 × 10⁸ m/s.
Planck’s constant, h, relates a photon’s energy to its frequency; photon energy increases with frequency and decreases with wavelength.
In the photoelectric effect, light ejects electrons from metal only when its frequency exceeds a threshold—raising the intensity of below-threshold yellow light will not eject electrons.

8:30 Rutherford’s Nuclear Atom and Bohr’s Quantized Energy Levels

Rutherford’s planetary model placed electrons around a dense nucleus; Bohr added that electron energies occupy specific, non-arbitrary levels.
Bohr’s hydrogen energy expression is Eₙ = −K/n², with K = 2.18 × 10⁻¹⁸ J supplied on the equation sheet.
As principal quantum number n increases, energy becomes less negative and approaches zero, representing an electron less tightly bound to the atom.

13:30 Electron Transitions: Final Energy Minus Initial Energy

The transition equation uses ΔE = −K(1/n₍final₎² − 1/n₍initial₎²), so the order must be final minus initial.
The equation sheet’s n₁ and n₂ labels can be misleading; they do not inherently mean initial and final states.
An electron moving to a higher level gains energy and has positive ΔE; moving to a lower level loses energy and has negative ΔE.

18:35 Quantized Transitions Require Exact Photon Energies

Electrons absorb a photon only when its energy matches the gap between two allowed energy levels.
Electrons emit electromagnetic radiation when they drop to a lower energy level, releasing energy equal in magnitude to the level difference.
The levels are quantized, so an electron cannot settle at an arbitrary energy between allowed states.

23:50 Why Bohr Energy Levels Converge at Higher n

Bohr’s shell diagram shows progressively smaller energy gaps between higher levels: the n = 1 to 2 gap is larger than gaps farther out.
An electron excited from n = 1 to n = 4 crosses the n = 1 to 2 gap plus additional energy gaps.
The model is useful for energy calculations but does not accurately portray the electron’s full spatial behavior.

27:15 Calculating Energy for the 1→2 and 2→4 Transitions

Students calculate absorbed energy for n = 1 to 2 and n = 2 to 4 using K and the final-minus-initial formula.
The class checks that the n = 1 to 2 transition has the larger energy gap, despite n = 2 to 4 spanning two level steps.
John Flood emphasizes parentheses in calculator entries and checking whether an electron is gaining or losing energy before trusting a sign.

34:30 Transition Signs, Energy Magnitudes, and Photon Energy

Reversing a transition’s initial and final levels preserves the magnitude of ΔE but changes its sign.
The energy of a photon is always positive, so photon energy equals the absolute value of the electron’s energy change: E₍photon₎ = |ΔE₍electron₎|.
Scientific-notation exponents matter when comparing values; a coefficient that looks larger can still represent less energy if its power of ten is smaller.

40:40 From Electron Transitions to Elemental Line Spectra

Excited atoms emit specific wavelengths as electrons fall between allowed levels, producing an emission line spectrum.
An absorption spectrum records the specific photon energies an atom can absorb to excite its electrons.
A prism separates the component wavelengths in emitted light; apparent white light combines many wavelengths rather than being a single wavelength.

42:00 Setting Up the 410 nm Hydrogen Transition Problem

The exercise asks which hydrogen transition absorbs a 410 nm photon and begins by identifying the electron’s initial state as ground-state n = 1.
The plan is to convert wavelength into photon energy with E = hc/λ, then equate that energy to the magnitude of the electron’s transition energy.
Solving for the unknown final level requires rearranging the Bohr transition equation for n₍final₎.

45:35 Converting Nanometers and Calculating Photon Energy

Convert 410 nm to meters before using Planck’s constant and the speed of light in E = hc/λ.
Use h = 6.626 × 10⁻³⁴ J·s and c = 2.998 × 10⁸ m/s; check that seconds and meters cancel, leaving joules.
John Flood recommends explicit conversion factors and calculator parentheses to reduce unit and exponent errors.

51:30 Algebra for Solving the Unknown Final Energy Level

Rearranging the transition equation isolates n₍final₎ as the square root of 1 divided by (1/n₍initial₎² − ΔE/K).
For an initial state of n = 1, students substitute the photon energy and K, then take the square root to estimate the final level.
The calculation produces a non-integer result rather than an allowed principal quantum number, prompting the class to inspect the problem’s assumptions.

58:50 Why the 410 nm Exercise Does Not Fit the Bohr Calculation

John Flood repeats the calculation and recognizes that the 410 nm wavelength was taken from hydrogen’s line spectrum but does not match the assumed ground-state transition in the simplified setup.
Because allowed Bohr levels require integer n values, a result such as approximately 1.13 cannot represent a valid final shell.
The instructor withdraws the exercise rather than presenting the inconsistent answer as a real electron transition, while retaining its algebra practice value.

1:08:00 Finding the Wavelength Emitted in the Hydrogen 4→1 Transition

For an electron falling from n = 4 to hydrogen’s ground state, n = 1, the transition energy is negative because the electron emits energy.
Using ΔE = −K(1/1² − 1/4²) gives an energy change whose magnitude is about 2.04 × 10⁻¹⁸ J.
The emitted photon’s wavelength follows from λ = hc/|ΔE|; unit cancellation yields meters, which can then be converted to nanometers.

1:16:00 Comparing Transition Wavelengths and Reading Hydrogen’s Spectrum

The n = 4 to 1 transition produces higher-energy, shorter-wavelength light than the smaller n = 1 to 2 energy gap.
Hydrogen’s spectrum has groups of closely spaced short wavelengths and more separated longer wavelengths, consistent with energy levels converging at higher n.
Hydrogen has only one electron, so its possible transitions are more limited than those of atoms with many interacting electrons.

1:25:10 Optical Emission Spectroscopy Identifies and Measures Elements

Optical emission spectroscopy (OES) uses element-specific emission wavelengths to identify which elements are present.
The intensity of emitted light can also help quantify how much of an element is present.
Different elements can have overlapping or similar wavelengths, so analysts must account for spectral interferences; isotopes generally retain similar electron transitions because they have the same electrical charge.

1:33:35 Matter Waves and the de Broglie Relationship

Wave-particle duality applies to matter as well as light: particles such as electrons also have wave behavior.
The de Broglie relationship connects wavelength to Planck’s constant, mass, and velocity; John Flood postpones a worksheet question after noticing ambiguity in its notation and units.
Transmission and scanning electron microscopes exploit electrons’ short wavelengths to resolve features that visible-light microscopy cannot distinguish.

1:38:45 The Double-Slit Experiment Shows Electron Interference

Waves passing through two slits form constructive and destructive interference patterns on a screen.
Electrons also produce interference patterns, even when sent through the apparatus one at a time.
The result is described through wave-like probabilities rather than treating each electron solely as a tiny classical particle following a definite path.

1:41:15 Heisenberg Uncertainty and Schrödinger’s Wave Function

Heisenberg’s uncertainty principle says position and momentum cannot both be known with arbitrary precision for an electron.
John Flood introduces a simplified form of Schrödinger’s equation, Ĥψ = Eψ, where Ĥ represents a mathematical operator, ψ is the wave function, and E is energy.
Squaring the wave function gives probability density, describing how likely an electron is to be found in regions of three-dimensional space.

1:45:10 The 1s Orbital: A Spherical Ground-State Probability Distribution

An orbital is not a planetary orbit; it describes the size, shape, and orientation of an electron’s probability distribution.
Hydrogen’s 1s orbital is the smallest orbital and has a spherical shape with no preferred orientation.
The radial probability distribution is low at the nucleus and higher away from it, reflecting the low probability of finding the electron directly at the nucleus.

1:47:00 The 2s Orbital, Phase Changes, and Radial Nodes

The 2s orbital has an inner and an outer spherical region with different phases of the wave function.
A node is a region where electron density is zero; in the 2s example, a spherical node separates the two regions.
The phase shading represents different wave-function behavior, not a claim that an electron literally rises and falls like an ocean wave.

1:49:00 The 3s Orbital and the Next Types of Nodes

The 3s orbital has two spherical nodes and alternating regions of wave-function phase.
John Flood previews spherical and angular nodes as building blocks for describing electron behavior in atoms.
The lesson closes by distinguishing quantum orbitals from circular Bohr paths and setting up further study of orbital shapes.
