EE 2115-03 - Lec 17 - 2026_10_05

Overview

Hiren Trada explains how negative feedback controls op-amp gain, then develops inverting and non-inverting amplifier analysis using ideal-op-amp assumptions, voltage dividers, KCL, and Ohm’s law. The lecture shows how a loaded, two-stage divider made from 51 kΩ, 2 kΩ, and two 1 kΩ resistors produces an effective feedback fraction of 1/104, and derives the standard gains −R2/R1 and 1 + R2/R1.

Key takeaways

Negative feedback lets an op amp avoid open-loop saturation by driving its input-terminal difference toward zero and setting gain through the feedback network.
A 51 kΩ resistor in series with an effective 1 kΩ lower branch returns about 1/52 of the output; halving that signal again with equal 1 kΩ resistors gives 1/104 feedback.
The ideal closed-loop gain is −R2/R1 for an inverting amplifier and 1 + R2/R1 for a non-inverting amplifier; the negative sign represents waveform inversion.
Negligible op-amp input current allows KCL to equate currents through the input and feedback resistors, making Ohm’s law a direct route to amplifier gain.
Virtual short means the input-terminal voltages are approximately equal under negative feedback, while virtual ground is the special case where one grounded input keeps the other near 0 V.

Chapters

0:00 Op-Amp Feedback: From Open-Loop Saturation to Controlled Gain

An ideal op amp has infinite input resistance, zero output resistance, infinite open-loop gain, and infinite bandwidth; practical devices approximate these properties.
Open-loop gain can drive the output beyond the available supply rails, so an op amp typically uses negative feedback to set a usable closed-loop gain.
Directly feeding the output to the inverting input creates a unity-gain voltage follower; feeding back only a fraction of the output allows larger gains.

5:00 Why a Single Feedback Divider Can Be Impractical

A feedback divider using 51 kΩ and 2 kΩ produces a gain of about 26.5 in the non-inverting configuration.
A target gain near 100 from one divider may require a much larger resistor ratio, such as 100 kΩ to 1 kΩ.
Very large resistance values can reduce current, and practical designs may be limited to available resistor values or benefit from using equal-valued on-chip resistors.

7:00 Building a Multi-Stage Feedback Divider

Trada introduces cascaded voltage-divider stages to reduce the returned feedback fraction without relying on one extreme resistor ratio.
The first divider creates an intermediate voltage Vx; a second divider made from two equal 1 kΩ resistors halves Vx before it reaches the inverting input.
Additional divider stages can further reduce the feedback signal and increase the resulting closed-loop gain.

13:00 Accounting for Divider Loading and the 1/104 Feedback Fraction

The added 1 kΩ + 1 kΩ stage is a 2 kΩ load in parallel with the original 2 kΩ resistor, giving an effective lower resistance of 1 kΩ.
With 51 kΩ in series with that effective 1 kΩ, the first divider returns approximately 1/52 of its input voltage.
The second equal-resistor stage halves that fraction again, producing an overall feedback fraction of 1/104 and a corresponding gain near 104.
For a 50 mV input amplitude, a gain near 104 predicts an output amplitude of about 5.2 V; LTspice can verify the result.

19:00 How Negative Feedback Brings Op-Amp Inputs Toward Equality

Negative feedback drives the op amp to reduce the difference between its inverting and non-inverting input voltages.
The two input voltages are not exactly equal at every instant in a real circuit because the response takes finite time.
The op amp amplifies the differential input; a common signal at both inputs is rejected in the idealized analysis.

23:30 Deriving the Inverting Gain with a Weighted Divider

The inverting configuration applies Vin through the input resistor to the inverting terminal and grounds the non-inverting terminal.
The feedback-node voltage is a weighted combination of Vin and Vout, derived using superposition and the assumption of negligible op-amp input current.
Using the large open-loop-gain approximation gives the standard inverting gain: Vout/Vin = −R2/R1.
The minus sign indicates that the output waveform is inverted relative to the input.

29:00 Checking Inversion in LTspice and Applying KCL

An LTspice example powered from +10 V and −10 V shows an amplified, inverted response to a small input signal.
A second derivation defines currents through R1 and R2, assumes negligible current enters the op-amp input, and applies KCL to set the resistor currents equal.
With the non-inverting terminal grounded, negative feedback holds the inverting node near 0 V, yielding Vout/Vin = −R2/R1 through Ohm’s law.

37:00 Deriving Non-Inverting Gain and Reviewing the Standard Forms

For a non-inverting amplifier, Vin is applied to the positive terminal and feedback forces the negative terminal toward the same voltage.
The voltage across R1 is approximately Vin, so IR1 = Vin/R1; zero input current makes IR2 equal IR1.
Adding the voltage across R2 to the voltage across R1 gives Vout/Vin = 1 + R2/R1.
The standard closed-loop gains are 1 + R2/R1 for non-inverting amplifiers and −R2/R1 for inverting amplifiers.

43:00 Virtual Short, Virtual Ground, and a Circuit-Analysis Checklist

With negative feedback and high open-loop gain, the two input terminals are treated as having nearly equal voltage even though they are not physically connected; this is the virtual-short approximation.
If the non-inverting input is physically grounded, the inverting input is approximately 0 V by virtual ground, a useful condition for analyzing inverting amplifiers.
For an unfamiliar circuit, first identify negative feedback, then determine whether the input enters the inverting or non-inverting terminal.
The closing exercise identifies an inverting amplifier with its non-inverting input grounded and asks students to determine whether a resistor affects the output; Trada recommends analyzing it rather than relying only on LTspice.
