ECE344 Fall 2026 (Sec 1) Lec 4 - Process Creation

Overview

Jon Eyolfson explains Unix process creation through the process control block, process states, and the complementary system calls fork and execve. He traces how fork duplicates a running process, how its parent and child continue independently with different return values, and how shells use fork followed by execve to launch commands; POSIX spawn offers a safer alternative for common cases.

Key takeaways

fork returns different values in its two processes: zero in the child and the child's PID in the parent, allowing both to choose separate control-flow paths.
Copy-on-write makes fork initially memory-efficient, but parent and child still have independent process state and can diverge when either modifies memory.
Repeated fork calls multiply processes: two consecutive forks can produce four, and a fork in each loop iteration can double the total again.
Process output order across parent and child is nondeterministic, but each process's own instruction order remains consistent.
execve replaces the current program image and does not return on success; shells combine it with fork to launch commands while retaining the shell process.
The fork-to-exec interval enables setup such as redirecting file descriptor 1, while POSIX spawn offers a higher-level way to configure such actions.

Chapters

0:00 Process Control Blocks Track Linux and xv6 Processes

The kernel manages each user-mode process, including its registers, virtual memory, and file descriptors.
Linux stores process bookkeeping in the task_struct; xv6 uses struct proc in proc.h.
A process control block includes saved registers, scheduling and memory information, open file descriptors, accounting data, and a unique PID.

2:52 The Five Process States: Ready, Running, Blocked, and Terminated

A process moves among ready, running, blocked, and terminated states after it is created and its executable is loaded.
Ready means waiting for CPU time; blocked means waiting for another event, such as a disk read.
The kernel can preempt a running process back to ready, unblock it when an event finishes, or terminate it when execution ends.
Linux exposes process information through /proc/PID/status; tools such as top inspect the /proc tree.

7:20 Unix Splits Process Creation Between fork and execve

Unlike Windows' CreateProcess API, which takes many arguments, Unix separates cloning a process from loading a new program.
fork creates a child process based on the currently running process; execve replaces a process image with a specified executable.
The fork call returns -1 on failure, 0 in the child, and the child's positive PID in the parent.
getpid and getppid report a process's own PID and its parent's PID.

12:00 What fork Copies: Memory, Registers, and File Descriptors

After fork, parent and child resume at the same point with independent virtual memory and register state.
Copy-on-write lets the processes initially share memory pages, copying a page only when one process modifies it.
The child inherits file descriptors, so parent and child can both write to the same terminal; either process can later redirect its own descriptor.
Use man 2 fork for system-call documentation and man 3 printf for C library documentation.

16:45 Reading fork's Two Return Values in a Parent-Child Example

A fork example branches on the return value: the parent receives the child's PID, while the child receives zero.
getpid and getppid confirm that the parent's fork result matches the child's PID and that the child's parent PID matches the original process.
Both processes execute the code after fork, so output from both branches appears even though each individual process follows only one branch.

21:30 Scheduling Makes Output Order Unpredictable; Repeated fork Multiplies Processes

The kernel chooses which process runs after fork, so parent and child output order is nondeterministic even if one order is common.
Each process that calls fork creates another child: two successive forks can produce four processes.
A fork inside a loop can double the process count on each iteration, quickly consuming system resources.
Execution order remains consistent within each process even though output interleaving between processes is unpredictable.

27:40 Trace Process Ancestry and fork Calls with /proc and strace

A program launched from a shell such as zsh descends from that shell through the process parent-child chain.
The /proc/PID/status file reveals a process name and state, allowing users to inspect a parent process by PID.
Run strace -f to follow child processes; the trace shows fork implemented through Linux's clone system call.
strace labels system calls with process IDs, making it possible to distinguish parent and child activity.

33:45 Returning from a Forked Function Can Create Extra Process Generations

In a loop that forks four children, calling exit in each child prevents it from returning to the parent's loop.
Replacing exit with return sends the child back to the code that called the function, where it can continue the loop and fork again.
That small control-flow change can produce 16 processes rather than the intended four children plus the original process.

40:35 execve Replaces the Process Image and Starts a New Program

execve takes an executable path, a null-terminated argv array, and an environment-variable array.
On success, the process keeps its identity but replaces its program image and begins executing the new program, such as /bin/ls.
Successful execve never returns to the old code; it returns only when an error occurs, so error-handling code after the call handles failure.
The new program inherits file descriptors unless they are changed before execve.

45:10 argv[0], Shell Redirection, and the POSIX spawn Alternative

argv[0] conventionally names the program, although the executable path and argv[0] do not have to match.
Programs that assume argv[0] exists can mishandle an empty argument vector; Eyolfson cites a sudo bug as an example of the risks.
A shell commonly runs a command by forking, adjusting the child's file descriptors for redirection if needed, then calling execve.
POSIX spawn provides a higher-level alternative that performs process creation and configured file actions without requiring application code to manage the fork-to-exec interval.
