Dynamics, Lectures 9 & 10: Oxford Mathematics 1st Year Student Lecture

Overview

Oxford Mathematics lectures 9 & 10 explore constrained motion, starting with the classic Atwood machine problem posed by Charles Dodgson (Lewis Carroll) and analyzing pendulum dynamics, including equilibrium, stability, and energy conservation. The lectures then delve into motion on surfaces of revolution, deriving equations of motion in cylindrical coordinates and demonstrating conservation of angular momentum. Finally, the course introduces Newton's law of gravitation and its application to planetary orbits (the Kepler problem), deriving the central force equation and outlining the mathematical trick using a `u = 1/r` substitution to solve for orbital paths.

Key takeaways

The period of a simple pendulum, when calculated exactly using energy conservation, involves an elliptic integral, deviating from the simple harmonic motion approximation for larger amplitudes.
For motion on a surface of revolution, conservation of angular momentum (r^2 * theta_dot = H) arises directly from the axial symmetry and the absence of a theta component in Newton's laws.
Newton's law of gravitation (F = -GmM/R^2 * R_hat) can be approximated by F = -mg near Earth's surface due to the large ratio of Earth's radius to the height of the object.
The Kepler problem (planetary orbits under an inverse square central force) can be solved by transforming the radial equation of motion using u = 1/r, leading to a second-order linear ODE in terms of theta: d^2u/d(theta)^2 + u = K/H^2.

Chapters

0:00 Introduction to the Atwood Machine and Dodgson's Challenge

Presents a frictionless pulley system with two 100kg masses: one pulled by gravity, the other a monkey.
Poses the question of what happens when the monkey climbs the rope, highlighting it as a constrained system.
Introduces Charles Dodgson (Lewis Carroll) as the originator of this problem.

3:35 Pendulum Dynamics: Newton's Second Law and Constraints

Reviews pendulum motion as a constrained system with a massless rod.
Derives Newton's second law in radial and tangential (theta) forms.
Notes that tension (T) in the rod is determined after solving for the angular motion.

5:16 Pendulum Equilibrium and Stability Analysis

Identifies two equilibrium points for the pendulum: theta = 0 (stable) and theta = pi (unstable).
Applies linear stability analysis by perturbing theta around equilibrium points.
Determines the stable equilibrium (theta=0) has an oscillation frequency of sqrt(g/l).

9:14 Pendulum Energy Conservation and Potential Energy

States that constraint forces (like rod tension) do no work in this system.
Defines total energy E as kinetic energy (1/2 M L^2 theta_dot^2) plus potential energy (-MGL cos theta).
Sets up the conservation of energy equation: E = constant.

13:56 Swinging a Pendulum Over the Top: Energy Requirements

Asks how much initial velocity is needed to swing a pendulum all the way to the top (theta = pi).
Determines that theta_dot must be non-zero at theta = pi for continuous motion.
Calculates the minimum energy required: E >= MGL, meaning initial velocity must be sufficient.

20:12 Pendulum Energy Landscape and Continuous Rotation

Visualizes potential energy V(theta) = -MGL cos theta as an energy landscape.
Shows that if total energy E > MGL, the pendulum will continuously rotate over the top.
Explains that without energy loss, the system behaves like a ball rolling over a hill.

22:33 Calculating the True Period of a Pendulum

Distinguishes between the linearized period (simple harmonic motion) and the actual period.
Sets up the integral for the period by rearranging the energy conservation equation.
The exact period involves an elliptic integral, not a simple 2*pi/omega.

24:04 Deriving the Period Integral for a Pendulum

Starts with the energy equation and solves for theta_dot squared.
Rearranges to get dt = d(theta) / sqrt(...), leading to an integral for time.
The period is found by integrating over a full cycle (e.g., from -theta_0 to theta_0).

31:53 Symmetry and Simplification of the Period Integral

Utilizes the symmetry of the potential energy to simplify the period integral.
The period can be calculated as 4 times the integral from 0 to theta_0.
Factors out sqrt(L/G) from the integral, leaving a dimensionless integral dependent on theta_0.

35:13 Interpreting the Pendulum Period Calculation

The integral part is dimensionless, confirming the T ~ sqrt(L/G) scaling.
The factor of 4 and the integral define the precise coefficient for the period.
Notes that the integral is an elliptic integral, often requiring numerical computation.

38:32 Condition for a Slackening Rod in a Pendulum

Discusses the physical meaning of the tension T in the pendulum rod.
If T becomes negative, it indicates the rod is pushing rather than pulling.
This signifies the rod becoming slack, analogous to a rope or snowboarder leaving a surface.

40:11 Introduction to Motion on a Surface and Gravity

Sets up the problem of a mass constrained to a surface under gravity.
Defines the normal reaction force (n) and gravity (G).
Assumes a smooth surface, meaning no friction and the normal force is perpendicular to the surface.

42:36 Constraint Force and Surface Normal Condition

States that the normal force (n) must be orthogonal to the surface.
The velocity vector (r_dot) is always tangent to the surface.
The condition n dot r_dot = 0 expresses this orthogonality.

1:00:06 Normal Force for Surfaces of Revolution

For a surface of revolution, the normal force has no component in the circumferential (e_theta) direction.
This means N dot e_theta = 0 due to axial symmetry.
This symmetry simplifies the analysis of forces.

1:01:40 Energy Conservation and Dimensionality Reduction

Highlights two approaches: Newton's laws or energy domain.
Energy conservation applies for conservative systems (gravity, smooth constraints).
The system is 2D (on the surface), not 3D, requiring reduction of variables.

1:05:56 Deriving Conservation of Angular Momentum (H)

Dots Newton's second law with the e_theta unit vector.
Uses the fact that N dot e_theta = 0 for surfaces of revolution.
Derives d/dt (r^2 * theta_dot) = 0, leading to conservation of r^2 * theta_dot = H.

1:12:12 Angular Momentum Conservation in Surfaces of Revolution

Confirms that the z-component of angular momentum (L0_z) is conserved for motion on a surface of revolution.
L0_z = M * r^2 * theta_dot = M * H.
This conservation arises from the axial symmetry of the system.

1:15:09 Eliminating the Normal Force (N) using Tau

Introduces a tangent vector (tau) to the curve of revolution (z = H(r)).
Dots Newton's second law with tau to eliminate the unknown normal force N.
Derives a complex equation involving r, theta_dot, z, and H'(r).

1:25:09 Reducing to a Single ODE for Radial Motion (r(t))

Uses the relationship z = H(r) and its derivatives (z_dot, z_double_dot) to eliminate z.
Substitutes H and its derivatives into the equation derived from tau dot Newton's law.
Results in a single, albeit messy, second-order ODE for r(t).

1:28:48 Example: Marble in a Parabolic Bowl (z = r^2 / 2a)

Considers a particle projected horizontally with speed V from height Z=a in a parabolic bowl.
Asks if the marble reaches the bottom (Z=0), considering no drag.
Uses conservation of energy (1/2 M |r_dot|^2 + MgZ = E) and angular momentum (r^2 theta_dot = H).

1:33:23 Calculating Initial Conditions and Total Energy

Determines initial conditions: Z(0)=a, R(0)=2a, R(0)theta_dot(0)=V.
Calculates H = R(0) * R(0)theta_dot(0) = 2aV.
Calculates total energy E = 1/2 M (H^2 / R(0)^2) + MgZ(0) = M V^2 / 2 + Mga.

1:47:39 Analyzing the Marble's Motion using an Effective Potential

Rewrites the energy equation in a form resembling T + V = constant.
Defines a 'curly T' (pseudo-kinetic) and 'curly V' (effective potential) that depend on Z.
Analyzes the shape of the effective potential V(Z) to determine allowed motion.
