Dynamics, Lectures 13 & 14: Oxford Mathematics 1st Year Student Lecture

Overview

These lectures introduce the concepts of angular momentum and torque for systems of particles, extending Newton's laws to rotational dynamics. The derivation shows that the rate of change of angular momentum (L_P dot) about a point P equals the net external torque about P, plus a term related to the velocity of P and the total linear momentum. Special cases for the origin and center of mass (G) are derived, leading to L_G dot = tau_G_external. The lectures also introduce the inertia tensor, a matrix that relates angular velocity to angular momentum for rigid bodies, highlighting how mass distribution affects rotational inertia.

Key takeaways

The rate of change of angular momentum about any point P equals the net external torque about P, plus a term accounting for P's motion relative to the center of mass.
For a system with no external forces, the center of mass moves with constant velocity (dP/dt = 0).
For a system with no external torques about the center of mass, angular momentum about G is conserved (dL_G/dt = 0).
Uniform gravity cannot create a torque about the center of mass, meaning it cannot induce rotation in an object initially at rest.
The relationship between angular momentum (L_G) and angular velocity (omega) for a rigid body is L_G = I_G * omega, where I_G is the inertia tensor.
The inertia tensor depends on the mass distribution and the chosen coordinate system, explaining why rotation can be easier around different axes.

Chapters

0:00 Review of Linear Momentum and Center of Mass

Linear momentum (P) of a system of particles satisfies dP/dt = sum of external forces.
This equation governs the translation of the center of mass (R_G).
Rotation is the missing component to fully describe system dynamics.

4:09 Defining Angular Momentum (L_P)

Angular momentum about point P is defined as L_P = sum of (r_i - x) cross (m_i * v_i).
r_i is the position vector of particle i, x is the position vector of point P.
v_i is the velocity of particle i.

7:00 Time Derivative of Angular Momentum

Calculating dL_P/dt involves differentiating the cross product sum.
Terms involving internal forces (F_ij) cancel out due to Newton's third law.
The derivative yields dL_P/dt = sum of (r_i - x) cross F_i_external + (x_dot - v_cm) cross P.

22:12 Defining External Torque (tau_P)

The term sum of (r_i - x) cross F_i_external is defined as the external torque about P (tau_P).
This represents the rotational effect of external forces about point P.

32:20 Angular Momentum Equation: L_P dot = tau_P_external + (x_dot - v_cm) cross P

The derived equation relates the rate of change of angular momentum to external torque and the motion of point P.
This equation holds for any arbitrary point P.

35:08 Special Case: Angular Momentum about the Origin (P=0)

If P is the origin (x=0), the equation simplifies to L_0 dot = tau_0_external.
This is a fundamental result: rate of change of angular momentum about the origin equals net external torque about the origin.

37:26 Special Case: Angular Momentum about the Center of Mass (P=G)

If P is the center of mass (G), x = R_G, and x_dot = R_G_dot.
The term (x_dot - v_cm) cross P becomes (R_G_dot - R_G_dot) cross P = 0.
This leads to L_G dot = tau_G_external, a key equation for rotational dynamics.

43:25 Missing Piece: Connecting Angular Momentum to Angular Velocity

Linear momentum P = M * R_G_dot relates momentum to velocity.
A similar relationship is needed for angular momentum L_G and angular velocity (omega).
This connection depends on mass distribution, not just total mass.

48:21 Intuitive Example: Forces on a Ruler

Applying forces in the same direction at both ends of a ruler results in translation (P_dot != 0) but no rotation (L_G_dot = 0).
Applying forces in opposite directions results in rotation (L_G_dot != 0) but no translation (P_dot = 0).

55:21 Torque due to Uniform Gravity

Uniform gravity (F_i = -m_i * g * k) acts on each particle.
The total external torque about point P is tau_P = sum of (r_i - x) cross (-m_i * g * k).
This simplifies to tau_P = (R_G - x) cross (-M * g * k).

1:02:36 Gravity's Torque about the Center of Mass

If P is the center of mass (G), then x = R_G.
The torque about the center of mass due to uniform gravity is tau_G = (R_G - R_G) cross (-M * g * k) = 0.
Uniform gravity cannot cause rotation about the center of mass.

1:05:47 Example: Spinning Top

Forces on a spinning top are gravity (mg) and the normal reaction force (N) at the contact point.
Torque about the center of mass (G) is due to the normal force: tau_G = a cross N.
Torque about the contact point (P) is due to gravity: tau_P = -a cross mgk.

1:13:56 Two-Body Problem: Binary Star System

For a closed system of two particles (m1, m2), Newton's third law implies F12 = -F21.
Summing their equations of motion shows M * R_G_dot_dot = 0, meaning the center of mass is inertial.
The relative position vector R = R1 - R2 satisfies mu * R_dot_dot = F12, where mu is the reduced mass.

1:30:32 Introduction to Rigid Bodies

A rigid body is a system of particles where the distance between any two particles remains constant.
This implies d/dt |r_i - r_j| = 0 for all i, j.
A rigid body has 6 degrees of freedom: 3 for translation and 3 for rotation.

1:37:37 Frames of Reference for Rotating Bodies

An inertial frame (S_hat) is fixed.
A non-inertial frame (S) can be attached to the rigid body, rotating with it.
The relationship between basis vectors of the two frames is given by a time-dependent rotation matrix R(t).

1:45:41 Angular Velocity Vector (omega)

The time derivative of the basis vectors of a rotating frame is given by d(e_i)/dt = omega cross e_i.
Omega is the angular velocity vector, defining the axis and rate of rotation.
This relationship arises from the properties of rotation matrices.
